HARTING09670154754Steckverbinder, D-Sub
Conn D-Sub F 15 POS 1.37mm Solder ST Thru-Hole 15 Terminal 1 Port
| Compliant with Exemption | |
| EAR99 | |
| Active | |
| 8536.69.40.40 | |
| SVHC | Yes |
| SVHC überschreitet Schwellenwert | Yes |
| Automotive | No |
| PPAP | No |
| D-Sub | |
| RCP | |
| 15 | |
| 15 | |
| 2 | |
| Solder | |
| 1.37 | |
| Straight | |
| F | |
| 7.5 | |
| 10000 | |
| 10 | |
| -55 | |
| 125 | |
| 50 | |
| Steel | |
| Tin | |
| A | |
| No | |
| 39.5 | |
| 12.5 | |
| Noble Metal Over Nickel | |
| Copper Alloy | |
| Through Hole |
The 09670154754 DVI connector from Harting is perfect for communication between serial connections in your system. This 2-row connector has a single port. It has a straight body orientation. Its pitch is 2.74 mm. This socket type connector has 15 socket type contacts. 09670154754 is housed in polybutylene terephthalate. This product is 39.5 mm long and 12.5 mm. Its 15 terminals use the solder termination method.
