HARTING09674155615Steckverbinder, D-Sub
Conn D-Sub M 15 POS Solder Cup ST Panel Mount 15 Terminal 1 Port
| Compliant with Exemption | |
| EAR99 | |
| Active | |
| SVHC | Yes |
| SVHC überschreitet Schwellenwert | Yes |
| Automotive | No |
| PPAP | No |
| D-Sub | |
| PL | |
| 15 | |
| 15 | |
| 2 | |
| Solder Cup | |
| Straight | |
| M | |
| 5 | |
| 5000 | |
| 10 | |
| -25 | |
| 70 | |
| 500 | |
| Brass | |
| Tin | |
| A | |
| 39.1 | |
| 14.3 | |
| Noble Metal Over Nickel | |
| Copper Alloy | |
| Panel Mount |
Using the 09674155615 DVI connector from Harting is fast and easy for communicating between serial connections in your circuit. It has a straight body orientation. This male connector has 15 male contacts. This 2-row connector has a single port. 09674155615 is housed in thermoplastic. This product is 39.1 mm long and 14.3 mm. Its 15 terminals use the solder cup termination method.
| EDA / CAD Models |
