PHOENIX CONTACT1953729Steckverbinderleisten und Leiterplattenbuchsen
Conn Wire to Board HDR 6 POS 3.5mm Solder RA Side Entry Thru-Hole Cardboard
| Compliant | |
| EAR99 | |
| Active | |
| 8536.69.40.40 | |
| Automotive | No |
| PPAP | No |
| Wire to Board | |
| HDR | |
| 6 | |
| 2 | |
| Solder | |
| 3.5 | |
| Right Angle | |
| 3.5 | |
| 8 | |
| 160V | |
| 5 | |
| 2.1 | |
| -40 | |
| 100 | |
| 25 | |
| Cardboard | |
| 2.62 | |
| 12 | |
| 13.3 | |
| 15.2 | |
| 2.6 | |
| Through Hole |
Mount this wire to board 1953729 header connector from Phoenix Contact on a jumper post on your PCB to support physical configuration options. This HDR connector has 6 contacts that are plated with tin. It has a right angle body orientation. Its pitch is 3.5 mm. This is a 2-row connector. It has a maximum voltage rating of 160 V. It has a header type gender. This device has a maximum current rating of 8 A. This product is 12 mm long, 15.2 mm tall and 13.3 mm deep. 1953729 is housed in black liquid crystal polymer. It uses the solder termination method.
| EDA / CAD Models |
