Analog DevicesEVAL-ADF4350EB1ZTakt und Timing Entwicklung Boards und Kits
ADF4350 Clock Generator and Synthesizer Evaluation Board
| Compliant | |
| EAR99 | |
| Active | |
| 8473.30.11.80 | |
| Automotive | No |
| PPAP | No |
| Evaluation Board | |
| ADF4350 | |
| Clock Generator and Synthesizer | |
| 10 | |
| USB | |
| 9(Max) |
Entwicklungskit-Beschreibung
The EVAL-ADF4350EB1Z is designed to evaluate the performance of the ADF4350 frequency synthesizer. It contains the ADF4350 synthesizer, a USB connector and related interface, a 25 MHz TCXO reference source, SMA connectors for the RF outputs, and reference signal plus headers for various signals and voltages. There is also a loop filter (35 kHz) on board. A USB cable is included with the board to connect to a PC USB port.
| EDA / CAD Models |
