| RoHS EU | Compliant |
| Part Status | Active |
| HTS | 8471.50.01.50 |
| Automotive | No |
| PPAP | No |
| Typ | Rack |
| Formfaktor | 1U |
| Prozessortyp | Intel |
| Prozessorfamilie | Xeon |
| Prozessoranzahl | E5-2600 v3 |
| Prozessorkerne | 18 Core |
| Prozessor Thermisches Design, Leistung (W) | 145 |
| Chipset-Typ | Intel C612 Express |
| Datenpufferspeichergröße (byte) | 45M |
| BIOS | 128Mb SPI Flash EEPROM with AMI |
| Systemspeicherart | DDR4 |
| Systemspeicher-Sockeltyp | DIMM |
| Systemspeicher, Anzahl der Fassungsstifte | 288 |
| Max. Größe des Systemspeichers (byte) | 1.5T |
| Systemspeichergeschwindigkeit (Hz) | 2133M/1866M/1600M |
| Nummer des Systemspeichers | 24 |
| USB | 5 |
| SATA | 4 |
| PCI | 0 |
| Ethernet-Karte, Anzahl der Steckverbinder | 4 |
| ECC-Unterstützung | Yes |
| Festplattenformfaktor (in) | 3.5 |
| Anzahl der Festplatteneinschübe | 4 |
| Anzahl der Lüfter | 4 |
| Mindestbetriebstemperatur (°C) | 10 |
| Max. Betriebstemperatur (°C) | 35 |
| Produktlänge (mm) | 437 |
| Produkttiefe (mm) | 777 |
| Produkthöhe (mm) | 43 |
