2.5V DC to DC Single Output Power Supply for Desktops and Servers
Referenzdesign unter Verwendung des Teils MAX1917 von Analog Devices
Bilder
1 / 1
Für Endprodukte
- DDR Memory
- Desktop PC Power Supply
- Desktops and Servers
- Game Console
- Graphics Card
- Set-Top Box
Beschreibung
- VDDQ Supply for Server DDR Memory Using PWM Step-Down Controller
Haupteigenschaften
-
Conversion TypeDC to DC
-
Input Voltage4.5 to 14 V
-
Output Voltage2.5 V
-
Output Current12 A
-
Efficiency96 %
Empfohlene Bauteile (4)
| Teilenummer | Hersteller | Typ | Beschreibung | |||
|---|---|---|---|---|---|---|
|
MAX1917EEE+ | Analog Devices | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 4.5V to 14V Synchronous Step Down Single-Out 0.4V to 5V 25A 16-Pin QSOP Tube | In den Warenkorb | |
|
|
MAX1917EEE+ | Analog Devices | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 4.5V to 14V Synchronous Step Down Single-Out 0.4V to 5V 25A 16-Pin QSOP Tube | In den Warenkorb | |
|
|
MAX1917EEE+T | Analog Devices | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 4.5V to 14V Synchronous Step Down Single-Out 0.4V to 5V 25A 16-Pin QSOP T/R | In den Warenkorb | |
|
|
MAX1917EEE+T | Analog Devices | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 4.5V to 14V Synchronous Step Down Single-Out 0.4V to 5V 25A 16-Pin QSOP T/R | In den Warenkorb | |
