ADP1853-EVALZ, Evaluation Board for the ADP1853 high efficiency, Step-Down DC to DC Controller
Referenzdesign unter Verwendung des Teils ADP1853ACPZ-R7 von Analog Devices
Bilder
1 / 2
Für Endprodukte
- Health System
- Industrial
- Instrumentation and Measurement
- Medical and Healthcare
- Optical Networking
- Wireless Base Station
Beschreibung
- ADP1853-EVALZ, Evaluation Board for the ADP1853 Step-Down DC to DC Controller. The input range for this evaluation board is 9 V to 15 V, and the regulated output voltage is 3.3 V with a maximum 20 A output current. A switching frequency (fSW) of 300 kHz is chosen to achieve a good balance between efficiency and the sizes of the power components
Haupteigenschaften
-
Conversion TypeDC to DC
-
Input Voltage9 to 15 V
-
Output Voltage3.3 V
-
Output Current20 A
-
Efficiency91 %
-
TopologyBuck
Empfohlene Bauteile (1)
| Teilenummer | Hersteller | Typ | Beschreibung | |||
|---|---|---|---|---|---|---|
|
ADP1853ACPZ-R7 | Analog Devices | DC to DC Controllers | DC/DC Cntrlr Single-OUT Step Down 1500kHz 20-Pin LFCSP EP T/R | In den Warenkorb | |
