CDCM7005BGA-EVM, Evaluation Board for the CDCM7005, 1300 MHz PLL Clock Generator for Clock and Timing Devices
Referenzdesign unter Verwendung des Teils CDCM7005ZVA von Texas Instruments
Bilder
1 / 5
Für Endprodukte
- Clock and Timing Devices
Beschreibung
- CDCM7005BGA-EVM, Evaluation Board for the CDCM7005, 1300 MHz PLL Clock Generator for Clock and Timing Devices. The CDCM7005 is a high-performance, low phase noise and low skew clock synchronizer that synchronizes an on-board voltage controlled crystal oscillator frequency to an external reference clock
Haupteigenschaften
-
Output Frequency1300 MHz
Empfohlene Bauteile (10)
| Teilenummer | Hersteller | Typ | Beschreibung | |||
|---|---|---|---|---|---|---|
|
SN74LV125ADR | Texas Instruments | Buffers and Line Drivers | Buffer/Line Driver 4-CH Non-Inverting 3-ST CMOS 14-Pin SOIC T/R | In den Warenkorb | |
|
OPA341UA | Texas Instruments | Operational Amplifiers - Op Amps | Op Amp Single Wideband Amplifier R-R I/O 5.5V 8-Pin SOIC Tube | In den Warenkorb | |
|
SN74LV125ADBR | Texas Instruments | Buffers and Line Drivers | Buffer/Line Driver 4-CH Non-Inverting 3-ST CMOS 14-Pin SSOP T/R | In den Warenkorb | |
|
YT1053530FPLFS | C&K | Switch Tactile | Switch Tactile OFF Mom SPST Round Button J-Lead 32VAC 32VDC 1VA 100000Cycles 3N SMD T/R | In den Warenkorb | |
|
|
KT11P3JM34LFS | C&K | Switch Tactile | Switch Tactile OFF Mom SPST Round Button J-Lead 32VAC 32VDC 1VA 100000Cycles 3N SMD T/R | In den Warenkorb | |
|
|
YT1053530FPLFS | C&K | Switch Tactile | Switch Tactile OFF Mom SPST Round Button J-Lead 32VAC 32VDC 1VA 100000Cycles 3N SMD T/R | In den Warenkorb | |
|
|
KT11P3JM34 LFS | C&K | Switch Tactile | Switch Tactile OFF Mom SPST Round Button J-Lead 32VAC 32VDC 1VA 100000Cycles 3N SMD T/R | In den Warenkorb | |
|
SN74LV125ADGVR | Texas Instruments | Buffers and Line Drivers | Buffer/Line Driver 4-CH Non-Inverting 3-ST CMOS 14-Pin TVSOP T/R | In den Warenkorb | |
|
CDCM7005ZVAR | Texas Instruments | Clock Generators and Synthesizers | Clock Generator 0MHz to 2.2GHz-IN 1500MHz-OUT 64-Pin BGA T/R | In den Warenkorb | |
|
|
CDCM7005ZVAT | Texas Instruments | Clock Generators and Synthesizers | Clock Generator 0MHz to 2.2GHz-IN 1500MHz-OUT 64-Pin BGA T/R | In den Warenkorb | |
