DLP4500-C350REF, High Resolution, Portable Light Steering Reference Design Using DLP Technology
Referenzdesign unter Verwendung des Teils DLPC350ZFF von Texas Instruments
Bilder
1 / 27
Zugehörige Dokumente
Für Endprodukte
- Imaging Device
- Industrial
- Industrial Imaging
Beschreibung
- DLP4500-C350REF, featuring the DLP 0.45 WXGA chipset and implemented in the DLP Light Crafter 4500 evaluation module (EVM), enables flexible control of high resolution, accurate patterns for industrial, medical, and scientific applications. With a free USB-based GUI and API, developers can easily integrate TIs innovative digital Micro-mirror device (DMD) technology with cameras, sensors, motors, and other peripherals to create highly differentiated 3D machine vision systems, 3D printers, and augmented reality displays
Haupteigenschaften
-
Embedded System TypeSoC
Empfohlene Bauteile (84)
| Teilenummer | Hersteller | Typ | Beschreibung | |||
|---|---|---|---|---|---|---|
|
TPS73025DBVR | Texas Instruments | Linear Regulators | LDO Regulator Pos 2.5V 0.2A 5-Pin SOT-23 T/R | In den Warenkorb | |
|
SN74AVC8T245PWRE4 | Texas Instruments | Level Translators | Voltage Level Translator CMOS to CMOS 8-CH Bidirectional 24-Pin TSSOP T/R | In den Warenkorb | |
|
NX3225SA 16.000MHz STD-CSR-6 | NIHON DEMPA KOGYO CO., LTD | Crystals | Crystal 16MHz ±15ppm (Tol) ±25ppm (Stability) 8pF FUND 80Ohm Automotive AEC-Q200 4-Pin SMD | In den Warenkorb | |
|
TPS54620RGYT | Texas Instruments | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 4.5V to 17V Synchronous Step Down Single-Out 0.8V to 15V 6A 14-Pin VQFN EP T/R | In den Warenkorb | |
|
|
NX3225SA14.31818MSTDCSR1 | NIHON DEMPA KOGYO CO., LTD | Crystals | Crystal 14.3182MHz ±15ppm (Tol) ±15ppm (Stability) 8pF FUND 80Ohm 4-Pin SMD | In den Warenkorb | |
|
|
TPS3838K33DBVT | Texas Instruments | Supervisory Circuits | Processor Supervisor 2.93V 1 Active Low/Open Drain 5-Pin SOT-23 T/R | In den Warenkorb | |
|
|
SN74AVC8T245PWR-P | Texas Instruments | Level Translators | Voltage Level Translator 8-CH Bidirectional 24-Pin TSSOP | In den Warenkorb | |
|
|
NX3225SA26.000000MHZB1 | NIHON DEMPA KOGYO CO., LTD | Crystals | Crystal 26MHz ±10ppm (Tol) ±10ppm (Stability) 10pF FUND 50Ohm 4-Pin SMD | In den Warenkorb | |
|
|
NX3225SA-16MHZ-STD-CSR-6 | NIHON DEMPA KOGYO CO., LTD | Crystals | Crystal 16MHz ±15ppm (Tol) ±25ppm (Stability) 8pF FUND 80Ohm Automotive AEC-Q200 4-Pin SMD | In den Warenkorb | |
|
|
NX3225SA 25.000MHz STD-CSR-6 | NIHON DEMPA KOGYO CO., LTD | Crystals | Crystal 25MHz ±15ppm (Tol) ±25ppm (Stability) 8pF FUND 50Ohm Automotive AEC-Q200 4-Pin SMD | In den Warenkorb | |
|
|
NX3225SA-12.000M-STD-CSR-3 | NIHON DEMPA KOGYO CO., LTD | Crystals | Crystal 12MHz ±15ppm (Tol) ±15ppm (Stability) 8pF FUND 100Ohm Automotive AEC-Q200 4-Pin SMD | In den Warenkorb | |
|
TPS65251RHAR | Texas Instruments | PMIC Solutions | Conv DC-DC 4.5V to 18V Synchronous Step Down Triple-Out 0.8V to 17V 3A/2A/2A 40-Pin VQFN EP T/R | In den Warenkorb | |
