DRV8811EVM, Evaluation Module Using DRV8811 Stepper Motor Controller for Laser and Motor Drives
Referenzdesign unter Verwendung des Teils DRV8811 von Texas Instruments
Bilder
1 / 3
Zugehörige Dokumente
Für Endprodukte
- Automatic Teller Machine
- Factory Automation
- Gaming and Toys
- Printers
- Robotics
- Scanners
Beschreibung
- DRV8811EVM, Evaluation Module EVM is complete solution for evaluating the DRV8811 micro stepping bipolar stepper driver. It houses a USB link to provide easy control from a PC computer, an MSP430 microcontroller that interprets serial commands from PC and generates control signals to driver device, and DRV8811 device with access to all signals for a complete evaluation
