LMZ10504DEMO/NOPB, Demo Board using LMZ10504 of 4A output current, 0.8 to 5V DC to DC Single Output Power Supply for Medical
Referenzdesign unter Verwendung des Teils LMZ10504EXTTZ von Texas Instruments
Bilder
1 / 2
Zugehörige Dokumente
Für Endprodukte
- Medical and Healthcare
- Military and Aerospace
- Portable
- Power Supplies
Beschreibung
- LMZ10504DEMO/NOPB, Demo Board SIMPLE SWITCHER power module is a complete, easy-to-use DC-DC solution capable of driving up to a 4A load with exceptional power conversion efficiency, output voltage accuracy, line and load regulation
Haupteigenschaften
-
Conversion TypeDC to DC
-
Input Voltage2.95 to 5.5 V
-
Output Voltage0.8 to 5 V
-
Output Current4 A
-
Efficiency96 %
Empfohlene Bauteile (6)
| Teilenummer | Hersteller | Typ | Beschreibung | |||
|---|---|---|---|---|---|---|
|
LMZ10504EXTTZE/NOPB | Texas Instruments | DC to DC Converter and Switching Regulator Module | Module DC-DC 1-OUT 0.8V to 5V 4A 20W 7-Pin TO-PMOD EP Tube | In den Warenkorb | |
|
|
LMZ10504EXTTZ/NOPB | Texas Instruments | DC to DC Converter and Switching Regulator Module | Module DC-DC 1-OUT 0.8V to 5V 4A 7-Pin TO-PMOD EP T/R | In den Warenkorb | |
|
|
LMZ10504EXTTZX/NOPB | Texas Instruments | DC to DC Converter and Switching Regulator Module | Module DC-DC 1-OUT 0.8V to 5V 4A 20W 7-Pin TO-PMOD EP T/R | In den Warenkorb | |
|
|
LMZ10504EXTTZ/NOPB | Texas Instruments | DC to DC Converter and Switching Regulator Module | Module DC-DC 1-OUT 0.8V to 5V 4A 7-Pin TO-PMOD EP T/R | In den Warenkorb | |
|
|
LMZ10504EXTTZE/NOPB | Texas Instruments | DC to DC Converter and Switching Regulator Module | Module DC-DC 1-OUT 0.8V to 5V 4A 20W 7-Pin TO-PMOD EP Tube | In den Warenkorb | |
|
|
LMZ10504EXTTZX/NOPB | Texas Instruments | DC to DC Converter and Switching Regulator Module | Module DC-DC 1-OUT 0.8V to 5V 4A 20W 7-Pin TO-PMOD EP T/R | In den Warenkorb | |
