LT3503 Demo Board, 1.2A, 2.2MHz Step-Down Switching Regulator in 2mm3mm DFN
Referenzdesign unter Verwendung des Teils LT3503EDCB von Analog Devices
Bilder
1 / 1
Für Endprodukte
- Automotive and Transportation
- Backplane Distributed Power
- Industrial Control
Beschreibung
- Demonstration circuit 1050 is a monolithic step-down DC/DC switching regulator featuring LT3503. The demo board is designed for 3.3V output from a 4.5V to 20V input. The wide input range of the LT3503 allows a variety of input sources. The typical sources are automotive batteries, wall adaptors and industrial supplies
Haupteigenschaften
-
Conversion TypeDC to DC
-
Input Voltage4.5 to 20 V
-
Output Voltage3.3 V
-
Output Current1 A
-
TopologyBuck
