LTC3789EGN Demo Board, High Efficiency Synchronous 4-Switch Step-Up/Step-Down DC/DC Converter
Referenzdesign unter Verwendung des Teils LTC3789EGN von Analog Devices
Bilder
1 / 3
Zugehörige Dokumente
Für Endprodukte
- Automotive and Transportation
- Battery Management
- Distributed Control System
- Industrial Control
Beschreibung
- Demonstration circuit DC1523A features the LTC3789EGN, a high efficiency switching step-up/down controller. The DC1523A input range is from 5V to 36V. The output voltage is 12V. The board is capable of delivering up to 5A of output current over the input voltage range
Haupteigenschaften
-
Conversion TypeDC to DC
-
Input Voltage5 to 36 V
-
Output Voltage12 V
-
Output Current5 A
-
Efficiency97 %
-
TopologyBuck Boost
Empfohlene Bauteile (2)
| Teilenummer | Hersteller | Typ | Beschreibung | |||
|---|---|---|---|---|---|---|
|
LTC3789EGN#PBF | Analog Devices | DC to DC Controllers | DC/DC Cntrlr Single-OUT Step Down/Step Up 710kHz 28-Pin SSOP N Tube | In den Warenkorb | |
|
|
LTC3789EGN#TRPBF | Analog Devices | DC to DC Controllers | DC/DC Cntrlr Single-OUT Step Down/Step Up 710kHz 28-Pin SSOP N T/R | In den Warenkorb | |
