MAX77324EVKIT#, Evaluation Kit for the MAX77324 4.8VIN, 1.5A High-Efficiency, Ultra-Small Buck Converter
Referenzdesign unter Verwendung des Teils MAX77324EWTAD+ von Analog Devices
Bilder
1 / 2
Für Endprodukte
- Battery Powered Equipment
- Internet of Things (IoT)
- Portable
- Space Constrained Equipment
- Wearable Electronics
Beschreibung
- MAX77324EVKIT#, Evaluation Kit (EV kit) provides a proven design to evaluate a high-efficiency synchronous stepdown DC-DC converter with integrated MOSFETs that operate over a 2.5V to 4.8V input voltage range, 0.6V to 2V output voltage range, and supports up to 1.5A of load current. The device automatically transitions between PWM and SKIP modes of operation when the load condition changes
Haupteigenschaften
-
Conversion TypeDC to DC
-
Input Voltage2.5 to 4.8 V
-
Output Voltage0.6 to 2 V
-
Output Current1.5 A
-
TopologyBuck
Empfohlene Bauteile (4)
| Teilenummer | Hersteller | Typ | Beschreibung | |||
|---|---|---|---|---|---|---|
|
MAX77324EWTAD+ | Analog Devices | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 2.5V to 4.8V Synchronous Step Down Single-Out 0.6V to 2V 1.5A 6-Pin WLP T/R | In den Warenkorb | |
|
|
MAX77324EWTAD+T | Analog Devices | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 2.5V to 4.8V Synchronous Step Down Single-Out 0.6V to 2V 1.5A 6-Pin WLP T/R | In den Warenkorb | |
|
|
MAX77324EWTAD+T | Analog Devices | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 2.5V to 4.8V Synchronous Step Down Single-Out 0.6V to 2V 1.5A 6-Pin WLP T/R | In den Warenkorb | |
|
|
MAX77324EWTAD+ | Analog Devices | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 2.5V to 4.8V Synchronous Step Down Single-Out 0.6V to 2V 1.5A 6-Pin WLP T/R | In den Warenkorb | |
