MAX8834YEVKIT+, Evaluation Kit for MAX8834Y 3-LEDs Flash LED Driver for Flash Camera
Referenzdesign unter Verwendung des Teils MAX8834YEWP+ von Analog Devices
Bilder
1 / 3
Zugehörige Dokumente
Für Endprodukte
- Flash Camera
Beschreibung
- MAX8834YEVKIT+, MAX8834Y Evaluation Kit is a fully assembled and tested PCB that demonstrates highly integrated MAX8834Y adaptive step-up converter with 1.5A flash driver. MAX8834Y flash driver integrates an adaptive 1.5A PWM step-up DC-DC converter, two 750mA white LED camera flash/movie current regulators, and a 16mA indicator LED current regulator
Haupteigenschaften
-
Input Voltage2.5 to 5.5 V
-
Output Current0.0005 to 0.016|0.0156 to 0.125|0.02244 to 0.75 A
-
Number of Derived Elements3
Empfohlene Bauteile (8)
