NCP1381 Demonstration Board 120 W Notebook Adapter with Power Factor Correction
Referenzdesign unter Verwendung des Teils NCP1381 von onsemi
Bilder
1 / 2
Für Endprodukte
- Laptop
- Notebook
Beschreibung
- NCP1381 Demonstration Board 120 W Notebook Adapter with Power Factor Correction. The NCP1381 is quasi-resonant controller developed to ease the design of 80 to 200 W switching power supplies requiring a Power Factor Correction (PFC) stage. One of its typical applications is notebook adapter power supply, in which high-efficiency, low standby power and low EMI are the key requirements
Haupteigenschaften
-
Conversion TypeAC to DC
-
Input Voltage90 to 265 (AC) V
-
Output Voltage180 to 385 V
-
Output Power120 W
-
Efficiency84.07 %
-
TopologyFlyback- Quasi Resonant
