PGA308EVM, Evaluation Kit consists of 2-Boards: PGA308 Test Board + USB DAQ Platform
Referenzdesign unter Verwendung des Teils PGA308AIDGST von Texas Instruments
Bilder
1 / 4
Für Endprodukte
- Automotive Sensor
- Strain Gauge
- Weigh Scale/Bridge Sensor
Beschreibung
- PGA308EVM, Evaluation Kit consists of 2-Boards: PGA308 Test Board + USB DAQ Platform. The PGA308 Test Board contains the PGA308, terminal strips for external connections, several jumpers for device configuration and support circuitry. The PGA308 Test Board can be used to fully test your design before prototyping it. The USB DAQ Platform contains an 8052 microcontroller with a built in USB interface. The microcontroller generates the one-wire signals necessary to communicate with the PGA308. The USB DAQ Platform also contains, a 3V/5V programmable linear regulator, a switch for power control, general purpose digital I/O, DAC outputs and A/D inputs
Empfohlene Bauteile (8)
| Teilenummer | Hersteller | Typ | Beschreibung | |||
|---|---|---|---|---|---|---|
|
OPA333AIDBVT | Texas Instruments | Operational Amplifiers - Op Amps | Op Amp Single Low Offset Voltage Amplifier R-R I/O ±2.75V/5.5V 5-Pin SOT-23 T/R | In den Warenkorb | |
|
XTR116UA/2K5E4 | Texas Instruments | Sensor and Detector Interface | Sensor and Detector Interface 36V 2-Wire Interface 8-Pin SOIC T/R | In den Warenkorb | |
|
|
XTR116UA/2K5E4 | Texas Instruments | Sensor and Detector Interface | Sensor and Detector Interface 36V 2-Wire Interface 8-Pin SOIC T/R | In den Warenkorb | |
|
|
XTR116UA/2K5 | Texas Instruments | Sensor and Detector Interface | Sensor and Detector Interface 36V 2-Wire Interface 8-Pin SOIC T/R | In den Warenkorb | |
|
|
XTR116UA/2K5 | Texas Instruments | Sensor and Detector Interface | Sensor and Detector Interface 36V 2-Wire Interface 8-Pin SOIC T/R | In den Warenkorb | |
|
LT3008ETS8-5#TRMPBF | Analog Devices | Linear Regulators | LDO Regulator Pos 5V 0.02A 8-Pin TSOT-23 T/R | In den Warenkorb | |
|
|
OPA333AIDBVTG4 | Texas Instruments | Operational Amplifiers - Op Amps | Op Amp Single Low Offset Voltage Amplifier R-R I/O ±2.75V/5.5V 5-Pin SOT-23 T/R | In den Warenkorb | |
|
PGA308AIDGST | Texas Instruments | Sensor and Detector Interface | Sensor and Detector Interface 5.5V 1-Wire Interface 10-Pin VSSOP T/R | In den Warenkorb | |
