PMP3061.5, (-12V @ 200mA) Multiphase, Sync Buck, Buck-Boost, Boost Reference Design
Referenzdesign unter Verwendung des Teils TPS40210DGQ von Texas Instruments
Bilder
1 / 1
Zugehörige Dokumente
Für Endprodukte
- Computers and Peripherals
Beschreibung
- PMP3061.5, (-12V @ 200mA) Multiphase, Sync Buck, Buck-Boost, Boost Reference Design. The PMP3061 is a multiple output power supply that supports a number of different rails. The input for this design is 12V with the following devices and outputs TPS40140 (1.2V@40A), TPS40190 (3.3V@6A), TPS54350 (-5V@200mA), TPS40210 (25V@1A), TPS5430 (-12V@200mA). The supply has a range of topologies also, multiphase sync buck (TPS40140), sync buck (TPS40190), negative output sync buck-boost (TPS54350), boost (TPS40210) and negative output buck-boost (TPS5430)
Haupteigenschaften
-
Conversion TypeDC to DC
-
Input Voltage22 to 26 V
-
Output Voltage25 V
-
Output Current1 A
-
Output Power25 W
-
TopologyBoost- Non Sync
Empfohlene Bauteile (2)
| Teilenummer | Hersteller | Typ | Beschreibung | |||
|---|---|---|---|---|---|---|
|
TPS40210 | Texas Instruments | DC to DC Controllers | DC/DC Cntrlr Single-OUT Step Up 1000kHz 10-Pin HVSSOP EP Tube | In den Warenkorb | |
|
|
TPS40210DGQ | Texas Instruments | DC to DC Controllers | DC/DC Cntrlr Single-OUT Step Up 1000kHz 10-Pin HVSSOP EP Tube | In den Warenkorb | |
