PMP8251, Xilinx Zynq FPGA Power Solution Reference Design
Referenzdesign unter Verwendung des Teils TPS54325PWP von Texas Instruments
Bilder
1 / 7
Zugehörige Dokumente
Für Endprodukte
- Audio
- Cellular Phone
- Consumer Electronics Control
- Industrial
- Portable Consumer Electronics
- Video and Imaging
Beschreibung
- PMP8251, Xilinx Zynq FPGA Power Solution Reference Design. The Reference design featuring multiple of the TPS54325 and other power devices, is a complete power solution for Xilinx Zynq FPGA. From 12V input, this reference solution provides all the power rails required by Zynq FPGA including DDR3 memory
Haupteigenschaften
-
Conversion TypeDC to DC
-
Input Voltage5 to 12 V
-
TopologyBuck
