TIDA-00140, XGA digital video SerDes 18bit to 24bit Upscale Solution for Automotive TFT LCD Displays
Referenzdesign unter Verwendung des Teils DS90UR905QSQ von Texas Instruments
Bilder
1 / 5
Beschreibung
- TIDA-00140, XGA digital video SerDes 18bit to 24bit Upscale Solution for Automotive TFT LCD Displays. The TIDA-00140 reference design is a high speed serial video interface to connect a remote automotive XGA TFT LCD display with 24 bit Parallel RGB Interface to a video processing system. Image enhancement features - dithering and white balance - optimize display performance. It uses TIs FPD-Link II SerDes technology to transmit uncompressed video data over shielded twisted pair cable. This design incorporates the SERDESUR-916ROS/NOPB board to create the solution
Empfohlene Bauteile (7)
| Teilenummer | Hersteller | Typ | Beschreibung | |||
|---|---|---|---|---|---|---|
|
78B03ST | Grayhill | Switch DIP | Switch DIP OFF ON SPST 3 Raised Slide 0.15A 30VDC PC Pins 2000Cycles 2.54mm Thru-Hole Tube | In den Warenkorb | |
|
DS90UR905QSQE/NOPB | Texas Instruments | LVDS | LVDS Serializer 1820Mbps 0.52V 48-Pin WQFN EP T/R Automotive AEC-Q100 | In den Warenkorb | |
|
|
DS90UR905QSQ/NOPB | Texas Instruments | LVDS | LVDS Serializer 1820Mbps 0.52V 48-Pin WQFN EP T/R Automotive AEC-Q100 | In den Warenkorb | |
|
|
DS90UR905QSQX/NOPB | Texas Instruments | LVDS | LVDS Serializer 1820Mbps 0.52V 48-Pin WQFN EP T/R Automotive AEC-Q100 | In den Warenkorb | |
|
|
DS90UR905QSQ/NOPB | Texas Instruments | LVDS | LVDS Serializer 1820Mbps 0.52V 48-Pin WQFN EP T/R Automotive AEC-Q100 | In den Warenkorb | |
|
|
DS90UR905QSQX/NOPB | Texas Instruments | LVDS | LVDS Serializer 1820Mbps 0.52V 48-Pin WQFN EP T/R Automotive AEC-Q100 | In den Warenkorb | |
|
|
DS90UR905QSQE/NOPB | Texas Instruments | LVDS | LVDS Serializer 1820Mbps 0.52V 48-Pin WQFN EP T/R Automotive AEC-Q100 | In den Warenkorb | |
