TIDA-00286, Variable threshold Hall proximity Sensor with PNP/NPN
Referenzdesign unter Verwendung des Teils DRV5053RAQDBZ von Texas Instruments
Bilder
1 / 3
Zugehörige Dokumente
Für Endprodukte
- Portable
- Wireless Sensor
Beschreibung
- TIDA-00286, Variable threshold Hall proximity Sensor with PNP/NPN. This Design offers a rapid prototyping platform for magnetic-field proximity sensor with PNP or NPN output. Thanks to its modular design, different options can be tried from magnetic threshold configurations, default to normally open or default to normally closed as well as PNP or NPN output stage. TIDA-00286 comes by default with a integrated Hall-sensor, a switch and LED for status indications. All this fitting in a 6mm wide PCB compatible with the industry standard M12 connector
Empfohlene Bauteile (6)
| Teilenummer | Hersteller | Typ | Beschreibung | |||
|---|---|---|---|---|---|---|
|
MSP430FR5738IRGET | Texas Instruments | Microcontrollers - MCUs | MCU 16-bit MSP430 RISC 2.5V/3.3V 24-Pin VQFN EP T/R | In den Warenkorb | |
|
SN65HVD101RGBR | Texas Instruments | PHY | PHY 1-CH 3.3V/5V 20-Pin VQFN EP T/R | In den Warenkorb | |
|
|
SN65HVD101RGBT | Texas Instruments | PHY | PHY 1-CH 3.3V/5V 20-Pin VQFN EP T/R | In den Warenkorb | |
|
|
MSP430FR5738IRGER | Texas Instruments | Microcontrollers - MCUs | MCU 16-bit MSP430 RISC 2.5V/3.3V 24-Pin VQFN EP T/R | In den Warenkorb | |
|
DRV5053RAQDBZR | Texas Instruments | Hall Effect Sensors | Hall Effect Sensor Bipolar 3.3V/5V/9V/12V/15V/18V/24V 3-Pin SOT-23 T/R | In den Warenkorb | |
|
|
DRV5053RAQDBZRQ1 | Texas Instruments | Hall Effect Sensors | Hall Effect Sensor Bipolar 3.3V/5V/9V/12V/15V/18V/24V Automotive AEC-Q100 3-Pin SOT-23 T/R | In den Warenkorb | |
