TIDM-SOMPLC-F28PLC83, System on Module for PRIME Power Line Communication (CENELEC Frequency Band)
Referenzdesign unter Verwendung des Teils TMS320F28069FPFPQ von Texas Instruments
Bilder
1 / 6
Zugehörige Dokumente
Für Endprodukte
- Power Line Communication
- Smart Electric Meter
- Solar Power
Beschreibung
- TIDM-SOMPLC-F28PLC83, System on Module for PRIME Power Line Communication (CENELEC Frequency Band). The SOMPLC-F28PLC83 is a single-board System on Module(SOM) for PLC in the CENELEC frequency band. This single hardware design supports Prime PLC industry standards. certified PLC software is available along with the SOMPLC-F28PLC83. Engineers can take the SOM design and integrate it into their overall system board or keep the design as an add-on board to their application. The only additional hardware required is the AC mains line coupling circuitry
Haupteigenschaften
-
Embedded System TypeMCU
-
Family NameC2000 Piccolo
-
Core ProcessorC28x
-
PlatformLaunchPad
Empfohlene Bauteile (8)
| Teilenummer | Hersteller | Typ | Beschreibung | |||
|---|---|---|---|---|---|---|
|
AFE031AIRGZT | Texas Instruments | Analog Front End - AFE | AFE General Purpose 3.3V 48-Pin VQFN EP T/R | In den Warenkorb | |
|
|
AFE031AIRGZR | Texas Instruments | Analog Front End - AFE | AFE General Purpose 3.3V 48-Pin VQFN EP T/R | In den Warenkorb | |
|
|
AFE031AIRGZ | Texas Instruments | Analog Front End - AFE | AFE General Purpose 3.3V 48-Pin VQFN EP T/R | In den Warenkorb | |
|
ABM3B-20.000MHZ-10-1-U-T | Abracon | Crystals | Crystal 20MHz ±10ppm (Tol) ±10ppm (Stability) 10pF FUND 50Ohm 4-Pin CSMD T/R | In den Warenkorb | |
|
SN74LVC2G07DBVR | Texas Instruments | Buffers and Line Drivers | Buffer/Driver 2-CH Non-Inverting Open Drain CMOS 6-Pin SOT-23 T/R | In den Warenkorb | |
|
|
SN74LVC2G07DBVRG4 | Texas Instruments | Buffers and Line Drivers | Buffer/Driver 2-CH Non-Inverting Open Drain CMOS 6-Pin SOT-23 T/R | In den Warenkorb | |
|
TPS3828-33DBVR | Texas Instruments | Supervisory Circuits | Processor Supervisor 2.93V 1 Active Low/Open Drain Automotive 5-Pin SOT-23 T/R | In den Warenkorb | |
|
TMS320F28069FPFPQ | Texas Instruments | Microcontrollers - MCUs | MCU 32-bit C28x RISC 256KB Flash 3.3V Automotive 80-Pin LQFP Tray | In den Warenkorb | |
