TPS65131EVM, Evaluation Module for TPS65131 Positive and Negative Output DC-DC Converter
Referenzdesign unter Verwendung des Teils TPS65131RGE von Texas Instruments
Bilder
1 / 1
Für Endprodukte
- Digital Camcorder
- Digital Camera
- LCD TFT Display
- OLED Display
- Personal Digital Assistant
Beschreibung
- TPS65131EVM, Evaluation Module uses a TPS65131 multi-channel output IC to provide both a positive and a negative power rail. The purpose of the EVM is facilitate evaluation of the TPS65131. All specifications are given for an ambient temperature of 25OC. The EVM operates with input voltages over the 2.5V to 5.5V recommended operating input voltage range for the TPS65131 IC
Haupteigenschaften
-
Conversion TypeDC to DC
-
Input Voltage3 to 3.6 V
-
Output Voltage-12|12 V
-
Output Current0.165@-12V|0.41@12V A
-
Efficiency85 %
-
TopologyBoost
Empfohlene Bauteile (4)
| Teilenummer | Hersteller | Typ | Beschreibung | |||
|---|---|---|---|---|---|---|
|
TPS65131RGERG4 | Texas Instruments | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 2.7V to 5.5V Step Down/Step Up Dual-Out -15V to -2V/3.2V to 15V 1.95A/1.95A 24-Pin VQFN EP T/R | In den Warenkorb | |
|
|
TPS65131RGET | Texas Instruments | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 2.7V to 5.5V Step Down/Step Up Dual-Out -15V to -2V/3.2V to 15V 1.95A/1.95A 24-Pin VQFN EP T/R | In den Warenkorb | |
|
|
TPS65131RGETG4 | Texas Instruments | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 2.7V to 5.5V Step Down/Step Up Dual-Out -15V to -2V/3.2V to 15V 1.95A/1.95A 24-Pin VQFN EP T/R | In den Warenkorb | |
|
|
TPS65131RGER | Texas Instruments | DC to DC Converter and Switching Regulator Chip | Conv DC-DC 2.7V to 5.5V Step Down/Step Up Dual-Out -15V to -2V/3.2V to 15V 1.95A/1.95A 24-Pin VQFN EP T/R | In den Warenkorb | |
