AMC1100EVM, Evaluation Board using AMC1100 single-channel precision isolation amplifier
Referenzdesign unter Verwendung des Teils AMC1100DUB von Texas Instruments
Bilder
1 / 5
Für Endprodukte
- Automotive and Transportation
- Communications and Telecom
- Computers and Peripherals
- Consumer Electronics
- Energy
- Industrial
- Lighting
- Medical and Healthcare
- Security
- Video and Imaging
Beschreibung
- AMC1100EVM, Evaluation Board using AMC1100 single-channel precision isolation amplifier with Screw terminals for easy access to analog inputs and outputs. The AMC1100 is a precision isolation amplifier with an output separated from the input circuitry by a silicon dioxide (SiO2) barrier that is highly resistant to magnetic interference. This barrier has been certified to provide basic galvanic isolation of up to 4000 VPEAK according to UL1577 and IEC60747-5-2 specifications
Haupteigenschaften
-
Gain8 dB
-
Number of SuppliesSingle
Empfohlene Bauteile (2)
| Teilenummer | Hersteller | Typ | Beschreibung | |||
|---|---|---|---|---|---|---|
|
AMC1100DUB | Texas Instruments | Special Purpose Amplifiers | SP Amp DIFF AMP Single 5.5V 8-Pin SOP Tube | In den Warenkorb | |
|
|
AMC1100DUBR | Texas Instruments | Special Purpose Amplifiers | SP Amp DIFF AMP Single 5.5V 8-Pin SOP T/R | In den Warenkorb | |
