PMP4302A, 90V to 264Vac input with 110W multi-transformer LED driver and 500mA per string
Referenzdesign unter Verwendung des Teils UCC25710DW von Texas Instruments
Bilder
1 / 3
Zugehörige Dokumente
Für Endprodukte
- LED Lighting
Beschreibung
- PMP4302A, 90V to 264Vac input with 110W multi-transformer LED driver and 500mA per string. 90V to 264Vac input with 110W multi-transformer LED driver and 500mA per string
Haupteigenschaften
-
Conversion TypeAC to DC
-
Input Voltage90 to 264 (AC) V
-
Output Voltage45 V
-
Output Current0.5 A
-
Output Power22.5 W
-
TopologyBoost
