PMP6797, 18Vdc-30Vdc Input,20V @ 4.5A Output,94% Efficient Active Clamp forward
Referenzdesign unter Verwendung des Teils UCC2897APW von Texas Instruments
Bilder
1 / 1
Zugehörige Dokumente
Für Endprodukte
- Communications and Telecom
Beschreibung
- PMP6797, 18Vdc-30Vdc Input,20V @ 4.5A Output,94% Efficient Active Clamp forward. 18Vdc-30Vdc Input,20V @ 4.5A Output,94% Efficient Active Clamp forward
Haupteigenschaften
-
Conversion TypeDC to DC
-
Input Voltage18 to 30 V
-
Output Voltage20 V
-
Output Current4.5 A
-
Output Power90 W
-
TopologyForward- Active Clamp|Forward- Synchronous
