TIDM-FRAM-WATERMETER, Water Meter Implementation with FRAM Microcontroller Reference Design
Referenzdesign unter Verwendung des Teils MSP430FR4133IPMR von Texas Instruments
Bilder
1 / 5
Zugehörige Dokumente
Für Endprodukte
- Gas and Water Meter
Beschreibung
- TIDM-FRAM-WATERMETER, Water Meter Implementation with FRAM Microcontroller Reference Design featuring the MSP430FR4133 FRAM-based MCU, is a fully-functional battery powered magnetic pulse water meter with wired and wireless automatic meter reading (AMR) function. The instantaneous and total flow is displayed on the LCD. This design works in low power mode and reduces CPU engagement, which helps to reduce overall power consumption
Haupteigenschaften
-
Embedded System TypeMCU
-
Family NameMSP430
Empfohlene Bauteile (6)
| Teilenummer | Hersteller | Typ | Beschreibung | |||
|---|---|---|---|---|---|---|
|
TSS721ADR | Texas Instruments | Bus Transceivers | Single Chip Meter Bus Transceiver | In den Warenkorb | |
|
DRV8837DSGR | Texas Instruments | Motor Controller and Driver ICs | H-Bridge Motor Driver 8-Pin WSON EP T/R | In den Warenkorb | |
|
AB26TRQ-32.768KHZ-T | Abracon | Crystals | Crystal 0.032768MHz ±20ppm (Tol) 12.5pF FUND 65000Ohm 2-Pin Mini-SMD T/R | In den Warenkorb | |
|
SN65HVD11SHKJ | Texas Instruments | Bus Line Transceivers | Single Transmitter/Receiver RS-485 8-Pin CFPAK Tube | In den Warenkorb | |
|
TPS78233DDCR | Texas Instruments | Linear Regulators | LDO Regulator Pos 3.3V 0.15A 5-Pin TSOT-23 T/R | In den Warenkorb | |
|
MSP430FR4133IPMR | Texas Instruments | Microcontrollers - MCUs | MCU 16-bit MSP430 RISC 15.5KB Flash 2.5V/3.3V 64-Pin LQFP T/R | In den Warenkorb | |
