TIPD188, High-Resolution, Low-Drift, Precision Weigh-Scale Reference Design with AC Bridge Excitation
Referenzdesign unter Verwendung des Teils ADS1263IPW von Texas Instruments
Bilder
1 / 4
Zugehörige Dokumente
Für Endprodukte
- Weigh Scale/Bridge Sensor
Beschreibung
- TIPD188, High-Resolution, Low-Drift, Precision Weigh-Scale Reference Design with AC Bridge Excitation. This precision weigh-scale reference design achieves greater than 50,000 noise-free counts of resolution. Offset and offset drift errors are nearly eliminated by ac bridge excitation. This design takes advantage of the high-resolution ADS1262 delta-sigma ADC
Haupteigenschaften
-
ADC Resolution32 Bit
-
Number of Channels1CH
Empfohlene Bauteile (2)
| Teilenummer | Hersteller | Typ | Beschreibung | |||
|---|---|---|---|---|---|---|
|
TS5A21366RSER | Texas Instruments | Analog Switch Multiplexers | Analog Switch Dual SPST 8-Pin UQFN T/R | In den Warenkorb | |
|
ADS1263IPW | Texas Instruments | Analog to Digital Converters - ADCs | 10-Channel Single ADC Delta-Sigma 38ksps 32-bit Serial 28-Pin TSSOP Tube | In den Warenkorb | |
